AL - Splices

Detailed technical specifications, reference attributes, and supporting compliance documents for AL - Splices.

View Specifications Download AL - Splices Catalog 13 variants

Category Variants

Explore Nearby Options

Category Variants

Nearby Options

13 options

Material:
Aluminium Alloy
Finish:
Electro Tin Plate

Specifications

Product Table

Compare the available part numbers, dimensions, and supporting data for this category.

Click Cat.No to expand product details.
Item Cat.No Wire Size Dimension (in.) Die Color Die Code
Code A ID OD
1 AS2571 250 kcmil 3.89 0.65 0.92 Red 71
2 AS2571-52 250 kcmil 2.92 0.59 0.91 Red 71
3 AS2571-62 250 kcmil 3.16 0.59 0.92 Red 71
4 AS3176 300 kcmil 3.95 0.71 0.99 Blue 76
5 AS3176-52 300 kcmil 3.10 0.65 1.01 Blue 76
6 AS3176-62 300 kcmil 3.18 0.65 1.01 Blue 76
7 AS3587 350 kcmil 4.95 0.75 1.09 Brown 87
8 AS3587-52 350 kcmil 3.35 0.72 1.12 Brown 87
9 AS3587-62 350 kcmil 4.02 0.72 1.11 Brown 87
10 AS4194 400 kcmil 4.95 0.81 1.18 Green 94
11 AS4194-52 400 kcmil 3.73 0.76 1.19 Green 94
12 AS4194-62 400 kcmil 4.84 0.76 1.19 Green 94
13 AS5199 500 kcmil 4.95 0.90 1.28 Pink 99
14 AS5199-52 500 kcmil 3.85 0.84 1.32 Pink 99
15 AS5199-62 500 kcmil 4.98 0.84 1.32 Pink 99
16 AS6106 600 kcmil 5.20 0.99 1.36 Black 106
17 AS6106-52 600 kcmil 4.10 0.92 1.44 Black 106
18 AS6106-62 600 kcmil 5.12 0.92 1.44 Black 106
19 AS7112 700 kcmil 5.42 1.06 1.44 Purple 112
20 AS7112-62 700 kcmil 5.24 1.06 1.46 Purple 112
21 AS7515 750 kcmil 5.67 1.10 1.50 Yellow 115
22 AS7515-52 750 kcmil 4.60 1.03 1.60 Yellow 115
23 AS0145 1 AWG 2.36 0.37 0.56 Gold 45
24 AS0145-52 1 AWG 1.98 0.35 0.53 Gold 45
25 AS0145-62 1 AWG 2.03 0.37 0.54 Gold 45
26 AS0242 2 AWG 1.79 0.31 0.51 Pink 42
27 AS0242-52 2 AWG 1.98 0.31 0.53 Pink 42
28 AS0242-62 2 AWG 2.42 0.31 0.53 Pink 42
29 AS0437 4 AWG 1.79 0.27 0.46 Green 94
30 AS0437-52 4 AWG 2.11 0.27 0.48 Green 94
31 AS0437-62 4 AWG 1.95 0.26 0.43 Green 94
32 AS0629 6 AWG 1.61 0.20 0.35 Gray 29
33 AS0629-52 6 AWG 1.60 0.20 0.34 Gray 29
34 AS0629-62 6 AWG 1.68 0.20 0.34 Gray 29
35 AS0824 8 AWG 1.17 0.17 0.28 Blue 24
36 AS0824-62 8 AWG 1.42 0.17 0.30 Blue 24
37 AS1050 1/0 AWG 2.36 0.41 0.62 Tan 50
38 AS1050-52 1/0 AWG 2.10 0.39 0.64 Tan 50
39 AS1050-62 1/0 AWG 2.35 0.39 0.60 Tan 50
40 AS2054 2/0 AWG 2.48 0.46 0.70 Olive 54
41 AS2054-52 2/0 AWG 2.29 0.45 0.69 Olive 54
42 AS2054-62 2/0 AWG 2.59 0.44 0.67 Olive 54
43 AS3060 3/0 AWG 2.79 0.52 0.77 Ruby 60
44 AS3060-52 3/0 AWG 2.60 0.48 0.76 Ruby 60
45 AS3060-62 3/0 AWG 2.86 0.48 0.76 Ruby 60
46 AS4066 4/0 AWG 3.64 0.60 0.86 White 66
47 AS4066-52 4/0 AWG 2.73 0.55 0.88 White 66
48 AS4066-62 4/0 AWG 3.04 0.55 0.85 White 66
